量程 | t | 10/20/30 | ||
精度 | C1 | C2 | C3 | |
最大分度值 | nmax | 1000 | 2000 | 3000 |
最小分度值 | vmin | Emax/3000 | Emax/5000 | Emax/10000 |
补偿误差 | (%FS) | ≤±0.05 | ≤±0.03 | ≤±0.02 |
蠕变 | (%FS/30min) | ≤±0.038 | ≤±0.024 | ≤±0.016 |
温度对输出灵敏度的影响 | (%FS/10℃) | ≤±0.028 | ≤±0.017 | ≤±0.011 |
温度对零点输出的影响 | (%FS/10℃) | ≤±0.047 | ≤±0.023 | ≤±0.015 |
输出灵敏度 | (mV/V) | 2.0±0.002 | ||
输入阻抗 | (Ω) | 700±7 | ||
输出阻抗 | (Ω) | 700±7 | ||
绝缘阻抗 | (MΩ) | ≥5000(50VDC) | ||
零点输出 | (%FS) | 1.5 | ||
温度补偿范围 | (℃) | -10~+40 | ||
工作温度范围 | (℃) | -35~+65 | ||
推荐激励电压 | (V) | 5~12(DC) | ||
最大激励电压 | (V) | 18(DC) | ||
安全过载范围 | (%FS) | 150 | ||
最大过载范围 | (%FS) | 300 | ||
